c11000 tinned coated copper busbar / flat copper bus bar for electrical
| Product Features | |
| *Material Standard | GB : T2 Copper with Min. 99.9%DIN: E-Cu58 (Number: 2.0065)EN: Cu-ETP ( Number: CW004A)ISO: Cu-ETPUNS: C11000JIS: C1100BS: C101Other Material also can be customized |
| *Conductivity | 57% |
| *Copper busbar thickness | 1mm-10mm depend on bus bar structure,we will advise suitable thickness |
| *Insulation Material | PVC Dipping Coating performs well for special shaped bus bar,which can be put on directly. It is not easy to break when it be bentwith many times. |
| *Flame Retardant/Fire Resistance | UL94-V-0 or upon you request |
| *Leakage Testing | PVC Dipping Sleeves: In condition of 3500VDC with 30s upon thickness 1.5mm, Leakage is 0.025 MA;In condition of 5000 VAC with 30s to 60s upon thickness 1.8mm to 2.0mm, Leakage is 0.065 MA;Or upon your working voltage, we advise to choose better solution. |
| *Surface Plating | Nickel, tin or silver plated etcPlating Thickness:Normally 3um to 12umor upon customers' request |
| *Salt Spray Testing | In a neutral environment, nickel can bear 240 hours. Silver is lower, tin is lowest |
| *Bending Testing | Bend 10000 times in 15 radian angle without breakage or fracture. |
| *Temperature Rise Testing | Depend on flexible busbar cross-sectional area,We can offer all temperature rising test report before delivery if you request |
| *Operating Temperature | -45 to +150 ºC |
| *Copper busbar Tensile Strength | ≥500N |
